Model SK-4000TV

Inquire product

New released mass production model 10kg for non vacuum or vacuum type up to customer’s requirement.

  • Revolution/Rotation individually speed can be controlled. (Rotation: 0-1.0 times speed changeable)
  • Max 10kg gross weight (5Kg x 2) throughput mass production model.
  • Customize model which 4,000ml standard container as well as specific container can be correspond.

4000 ml × 2 cups

Technical specifications
SK-4000TV
Type Vacuum equipped type
Container 4000ml HDPE container or SUS container
Max capacity 5kg(Including container) x 2 cups
Revolution speed 120 - 600 rpm, 9 levels
Rotation speed 0 -1.0 times against Rev speed, 10 levels
Setup time 10 -300 sec (10 decimal sec)
Step mode 1- 5 Step
Memory Channel Fixed CH: 10CH User settable CH: 90CH
Power source Three phase 200 -240V, 50/60Hz
Electric Max 15KVA
consumption Outer dimension W1,330×D1,010×H1,120 mm (Vacuum pump excluded)
Electric Approx. 700kg (Vacuum pump excluded)
Applications
  • - Battery manufacturers
  • - Electronic parts manufacturers
  • - Adhesive manufacturers
  • - Pigment and high functional material manufacturers
  • - Ceramic industry
  • - Defense and aerospace industry
  • - Cosmetic industry
  • - Medical and pharmaceutical industry
  • - Dental industry
