A Planetary Centrifugal Mixer with advanced technology of individual revolution and rotation speed control system performs the two conflicting processes of mixing and degassing simultaneously in a short period of time for a wide range of materials of different viscosity levels. Furthermore, it keeps the temperature of the material down.
2000ml × 2 cups (3kg)
Cup size | User designated (Max about 2000ml x 2 cup) Maximum 3kg (Gross Weight)x 2cups |
---|---|
Other containers | Multiple containers and syringes can be used by using an adapter. |
Speed of revolution | Settable in 9 steps |
Speed of rotation | Settable in 10 steps |
Settable time | 10-900 sec. (5 Step Total is 25 minutes.) |
Step mode | 5 steps Continuous operation with 5 different operation patterns (condition settings) is possible |
Memory channel (condition setting memory) User settable channels Fixed data channels | 90 10 |
Power supply voltage | Three phase AC200-240VAC 50/60Hz |
Power consumption | 3.0kW |
External dimensions | W726 × D743 × H860(㎜) |
Main unit weight | Approx. 270kg |
