Model SK-10000T
Inquire productNew released mass production model 20kg models for non vacuum or vacuum type up to customer’s requirement.
- Revolution/Rotation individually speed can be controlled. (Rotation: 0-1.0 times speed changeable)
- Max 20kg gross weight (10Kg x 2) throughput mass production model.
- Customize model which 7,000ml standard container as well as specific container can be correspond.
7000 ml × 2 cups
- Technical specifications
-
SK-10000T Type Standard type Container 7000ml HDPE container or SUS container Max capacity 10kg(Including container) x 2 cups Revolution speed 100 - 400 rpm, 9 levels Rotation speed 0 -1.0 times against Rev speed, 10 levels Setup time 10 -300 sec (10 decimal sec) Step mode 1- 5 Step Memory Channel Fixed CH: 10CH User settable CH: 90CH Power source Three phase 200 -240V, 50/60Hz Electric Max 20KVA consumption Outer dimension W1,900×D1,300×H980 mm Electric Approx. 1,500kg - Applications
-
- - Battery manufacturers
- - Electronic parts manufacturers
- - Adhesive manufacturers
- - Pigment and high functional material manufacturers
- - Ceramic industry
- - Defense and aerospace industry
- - Cosmetic industry
- - Medical and pharmaceutical industry
- - Dental industry
